Jinko Solar Panel
Item Solar PanelModel ✅ Jinko Tiger ProCell Type: P-type Mono-crystallineMBB HC Technology: YesMono-Facial Module: YesNo. of cells: 144 (6 x 24)Wind Speed: 1m/sCell Temperature: 25°CAmbient Temperature: 20°CSTC: Irradiance 1000W/m2NOCT: Irradiance 800W/m2Dimension2274 x 1134 x 35mm89.53 x 44.65 x 1.38 inchWeight: 28.9 KgFront Glass3.2mmAnti-Reflection CoatingHigh TransmissionLow IronTempered GlassFrame: Anodized Aluminium AlloyJunction Box: IP68 RatedMaximum Power (Pmax)STC: 550WNOCT: 409WMaximum Power Voltage (Vmp)STC: 40.90VNOCT: 38.42VMaximum Power Current (Imp)STC: 13.45ANOCT:10.65AOpen-circuit Voltage (Voc)STC: 49.62VNOCT: 46.84VShort-circuit Current (ISC)STC: 14.03ANOCT: 11.33AEnhanced Mechanical LoadWind Load: 2400 PascalSnow Load: 5400 PascalModule Efficiency STC: 21.33%Operating Temperature: 40℃~+85℃Maximum system voltage: 1000/1500VDC (IEC) Maximum series fuse rating: 25APower tolerance: 0~+3%Temperature coefficients of Pmax: -0.35%
Dipto Electronics Savar
Category List
All products
Details:
- Warranty25 years
Item Solar Panel
Model ✅ Jinko Tiger Pro
Cell Type: P-type Mono-crystalline
MBB HC Technology: Yes
Mono-Facial Module: Yes
No. of cells: 144 (6 x 24)
Wind Speed: 1m/s
Cell Temperature: 25°C
Ambient Temperature: 20°C
STC: Irradiance 1000W/m2
NOCT: Irradiance 800W/m2
Dimension
2274 x 1134 x 35mm
89.53 x 44.65 x 1.38 inch
Weight: 28.9 Kg
Front Glass
3.2mm
Anti-Reflection Coating
High Transmission
Low Iron
Tempered Glass
Frame: Anodized Aluminium Alloy
Junction Box: IP68 Rated
Maximum Power (Pmax)
STC: 550W
NOCT: 409W
Maximum Power Voltage (Vmp)
STC: 40.90V
NOCT: 38.42V
Maximum Power Current (Imp)
STC: 13.45A
NOCT:10.65A
Open-circuit Voltage (Voc)
STC: 49.62V
NOCT: 46.84V
Short-circuit Current (ISC)
STC: 14.03A
NOCT: 11.33A
Enhanced Mechanical Load
Wind Load: 2400 Pascal
Snow Load: 5400 Pascal
Module Efficiency STC: 21.33%
Operating Temperature: 40℃~+85℃
Maximum system voltage: 1000/1500VDC (IEC)
Maximum series fuse rating: 25A
Power tolerance: 0~+3%
Model ✅ Jinko Tiger Pro
Cell Type: P-type Mono-crystalline
MBB HC Technology: Yes
Mono-Facial Module: Yes
No. of cells: 144 (6 x 24)
Wind Speed: 1m/s
Cell Temperature: 25°C
Ambient Temperature: 20°C
STC: Irradiance 1000W/m2
NOCT: Irradiance 800W/m2
Dimension
2274 x 1134 x 35mm
89.53 x 44.65 x 1.38 inch
Weight: 28.9 Kg
Front Glass
3.2mm
Anti-Reflection Coating
High Transmission
Low Iron
Tempered Glass
Frame: Anodized Aluminium Alloy
Junction Box: IP68 Rated
Maximum Power (Pmax)
STC: 550W
NOCT: 409W
Maximum Power Voltage (Vmp)
STC: 40.90V
NOCT: 38.42V
Maximum Power Current (Imp)
STC: 13.45A
NOCT:10.65A
Open-circuit Voltage (Voc)
STC: 49.62V
NOCT: 46.84V
Short-circuit Current (ISC)
STC: 14.03A
NOCT: 11.33A
Enhanced Mechanical Load
Wind Load: 2400 Pascal
Snow Load: 5400 Pascal
Module Efficiency STC: 21.33%
Operating Temperature: 40℃~+85℃
Maximum system voltage: 1000/1500VDC (IEC)
Maximum series fuse rating: 25A
Power tolerance: 0~+3%
Temperature coefficients of Pmax: -0.35%
Jinko Solar Panel
12,760 BDT18,500 BDTSave 5,740 BDT
1
Details:
- Warranty25 years
Item Solar Panel
Model ✅ Jinko Tiger Pro
Cell Type: P-type Mono-crystalline
MBB HC Technology: Yes
Mono-Facial Module: Yes
No. of cells: 144 (6 x 24)
Wind Speed: 1m/s
Cell Temperature: 25°C
Ambient Temperature: 20°C
STC: Irradiance 1000W/m2
NOCT: Irradiance 800W/m2
Dimension
2274 x 1134 x 35mm
89.53 x 44.65 x 1.38 inch
Weight: 28.9 Kg
Front Glass
3.2mm
Anti-Reflection Coating
High Transmission
Low Iron
Tempered Glass
Frame: Anodized Aluminium Alloy
Junction Box: IP68 Rated
Maximum Power (Pmax)
STC: 550W
NOCT: 409W
Maximum Power Voltage (Vmp)
STC: 40.90V
NOCT: 38.42V
Maximum Power Current (Imp)
STC: 13.45A
NOCT:10.65A
Open-circuit Voltage (Voc)
STC: 49.62V
NOCT: 46.84V
Short-circuit Current (ISC)
STC: 14.03A
NOCT: 11.33A
Enhanced Mechanical Load
Wind Load: 2400 Pascal
Snow Load: 5400 Pascal
Module Efficiency STC: 21.33%
Operating Temperature: 40℃~+85℃
Maximum system voltage: 1000/1500VDC (IEC)
Maximum series fuse rating: 25A
Power tolerance: 0~+3%
Model ✅ Jinko Tiger Pro
Cell Type: P-type Mono-crystalline
MBB HC Technology: Yes
Mono-Facial Module: Yes
No. of cells: 144 (6 x 24)
Wind Speed: 1m/s
Cell Temperature: 25°C
Ambient Temperature: 20°C
STC: Irradiance 1000W/m2
NOCT: Irradiance 800W/m2
Dimension
2274 x 1134 x 35mm
89.53 x 44.65 x 1.38 inch
Weight: 28.9 Kg
Front Glass
3.2mm
Anti-Reflection Coating
High Transmission
Low Iron
Tempered Glass
Frame: Anodized Aluminium Alloy
Junction Box: IP68 Rated
Maximum Power (Pmax)
STC: 550W
NOCT: 409W
Maximum Power Voltage (Vmp)
STC: 40.90V
NOCT: 38.42V
Maximum Power Current (Imp)
STC: 13.45A
NOCT:10.65A
Open-circuit Voltage (Voc)
STC: 49.62V
NOCT: 46.84V
Short-circuit Current (ISC)
STC: 14.03A
NOCT: 11.33A
Enhanced Mechanical Load
Wind Load: 2400 Pascal
Snow Load: 5400 Pascal
Module Efficiency STC: 21.33%
Operating Temperature: 40℃~+85℃
Maximum system voltage: 1000/1500VDC (IEC)
Maximum series fuse rating: 25A
Power tolerance: 0~+3%
Temperature coefficients of Pmax: -0.35%
